Adding Battery Storage to an Existing Solar Setup

Why retrofit a battery instead of starting again

If your solar panels were installed any time in the last decade, the chances are they are still working perfectly well. Panels rarely fail, and most systems are warrantied for 25 years of output. What has changed is the economics around them. The old, generous export tariffs are long gone for most households, and the Smart Export Guarantee pays only a few pence per kilowatt hour. Meanwhile, evening electricity prices have climbed sharply.

That mismatch is exactly what a retrofit battery solves. Instead of sending your midday generation to the grid for 4p or 5p and buying it back at 25p or more after dark, you keep it. A well-sized battery can push your self-consumption from around 40% to 70% or more, and that is where the real savings sit. You do not need to touch the panels on the roof. You are simply adding the missing piece of the puzzle.

Can your existing inverter accept a battery?

This is the single question to answer before you spend anything. There are three common scenarios.

• Hybrid inverter already fitted. Some systems installed in the last five or six years use a hybrid inverter with a battery input sitting unused. If yours has one, the job is comparatively straightforward and often cheaper.
• Standard string inverter. The vast majority of UK installations use a straightforward solar-only inverter. These cannot manage a battery directly, so you will need an AC-coupled battery — a unit with its own built-in inverter that sits alongside your existing setup.
• Older or non-compatible kit. A small number of inverters, particularly some older models, cannot be easily integrated at all. In that case, a standalone AC-coupled battery is still the answer, but the installer will need to check the existing system's earthing arrangements and whether it can be monitored alongside.

Ask your installer to check the make, model and firmware of your inverter before quoting. It takes ten minutes and can save a lot of confusion later.

AC-coupled versus DC-coupled — the practical difference

Most retrofits are AC-coupled, and for good reason. The battery has its own inverter, so it charges from your existing solar via your consumer unit and discharges back into the house the same way. It is flexible, it works with almost any existing solar system, and it can also charge from cheap overnight electricity on a time-of-use tariff.

DC-coupled systems connect the battery to the solar array on the direct current side, before the inverter. They are marginally more efficient because there is one less conversion step, and they can keep the panels generating at a steady rate. But they usually mean replacing or adding to your existing inverter, which pushes the cost up considerably. For a retrofit, AC-coupled is nearly always the sensible call.

Space, siting and the details people forget

A battery is a physical box, and it needs somewhere sensible to live. A 5 kWh unit might be roughly the size of a small suitcase; a 10 kWh stack could be closer to a slim fridge-freezer. Think about where it will go before you buy.

• Temperature matters. Most lithium batteries prefer to sit between about 10°C and 30°C. A frosty detached garage can cause charging to pause in winter, and a baking loft can shorten life.
• Avoid escape routes. Building regulations guidance discourages placing batteries where they could block a means of escape. Hallways and under-stair cupboards are usually a poor choice.
• Ventilation and clearance. Manufacturers specify minimum gaps around the unit. Do not squeeze it into a corner to make it tidy.
• Cable runs. The further the battery sits from your consumer unit, the more cable and labour you are paying for. Keep it close if you can.

You will also need a notification to your distribution network operator for the battery's inverter, usually handled by your installer under the G98 or G99 process. Make sure that is included in the quote.

Sizing the battery to your actual evenings

There is a temptation to buy the biggest battery available. Resist it. Oversizing means paying for capacity you rarely use, and it lengthens the payback. A typical UK household on a standard tariff uses somewhere between 8 and 12 kWh a day in total, with perhaps 3 to 6 kWh of that falling after sunset.

If your solar generates 10 kWh on a decent spring day and you only export 4 kWh of it, a battery of around 5 kWh will comfortably soak up the surplus. Add more only if you plan to shift significant loads — an electric vehicle, a heat pump, or a switch to a tariff with a very cheap overnight window that you want to exploit.

A pre-purchase checklist

• Inverter model and firmware confirmed, with a written statement on whether it can be paired directly.
• Available space identified, with temperature and clearance checked against the manufacturer's spec.
• Quote includes DNO notification and any required electrical certification.
• Warranty terms understood — look at both the years and the guaranteed throughput in megawatt hours.
• Monitoring sorted, so you can see solar generation, battery state and household use in one place.
• Tariff reviewed alongside the battery, since a time-of-use tariff often unlocks extra value.

Get two or three quotes from installers who are certified under the Microgeneration Certification Scheme, and ask each of them the same questions. A good installer will happily talk you out of a battery that is too big for your usage — that is usually a sign you have found the right one.
